Oil Mist Filter

油霧/漆霧過濾器

Advantages 特點：

• Extremely effective for the oil mist and smoke

針對油霧,煙霧極為有效

• Ultra compact

非常簡潔，緊湊

• Extremely low resistance

阻力極低

• Humidity:100% RH

耐濕性：100% RH

Application: For oil mist filtration in ventilation system and exhaust system,such as the kitchen

應用: 用于通風系統(tǒng)和排風系統(tǒng)油霧的過濾，諸如廚房間

Specification 性能參數

Type: Pre-filter.

類型：預過濾器

Media: Glass fibre

濾材：玻璃纖維

Frame: Galvanized steel/Aluminum/Rigid water resistant cardboard.

外框材質：鍍鋅鋼板/鋁合金/耐高濕防水紙框

EN779:2011 filter class:G3(EN779), 90%≥EA≥80% @Arrestance efficiency

                                           G4(EN779), EA≥90% @Arrestance efficiency

過濾效率等級：G3(EN779), 90%≥EA≥80% @計重效率

                            G4(EN779), EA≥90% @計重效率

Recommended final pressure drop: 150 Pa.

建議終阻力：150Pa

Temperature: 150ºC maximum in continuous service.

連續(xù)穩(wěn)定運行溫度：不大于150ºC

Thickness vs Efficiency vs Pressrue drop

厚度/效率/阻力-對應關系表

Dimensions vs Air flow

長&寬尺寸/風量-對應關系表

Note：Pressure drop +/-15%

            Odd sizes available

注：阻力 +/-15%

        可定制任意非標尺寸
